Chapter 6: Console Configuration
The Personal Console Builder: Mix Bus Configuration
Eclipse User Guide 2.0 227/ 526
To change the format of the bus assignment:
3. Cursor down to the STEREO LR or STEREO LRC row
and press the [SPACE bar].
The assignment updates to the chosen format – in our example,
to stereo LR. Stereo bus assignments are represented by a
yellow box to indicate that they use multiple bus resources:
Notice that the mix bus resource counter decreases according
to the selected format:
A stereo LR bus uses 2 mix resources; a stereo LRC bus uses
3 mix resources.
4. To return a bus to mono, remove the STEREO LR pr
STEREO LRC format assignment.
5. Repeat for all the busses you wish to configure:
See Page 249 for details on patching mix busses to physical
outputs.
