Chapter 6: Console Configuration
The Personal Console Builder: Other Channel Types
228/ 526 2.0 Eclipse User Guide
Other Channel Types
The Personal Console Builder can assign three other channel
types as follows:
• VCA – a VCA master (yellow). See Page 193.
• MONITORING – a stereo monitoring fader (orange).
This fader will control the level of the selected monitor
output (01, 02 or 03). See Page 209.
• CROSSFADE – (white). This fader will control the
transition time between Pages when using automation.
See Page 378.
You can assign as many VCA masters as you like.
Only one MONITORING and one CROSSFADE fader may be
assigned at a time. The Monitoring fader is always stereo LR.
