Typical Applications
Error Specification (Includes Full-Scale,
Zero Error, and Non-Linearity)
Part Full- V
REF
/2
=
2.500 V
DC
V
REF
/2
=
No Connection
Number Scale (No Adjustments) (No Adjustments)
Adjusted
ADC0801
±
1
⁄ 4 LSB
ADC0802
±
1
⁄ 2 LSB
ADC0803
±
1
⁄ 2 LSB
ADC0804
±
1 LSB
ADC0805
±
1 LSB
DS005671-1
8080 Interface
DS005671-31
ADC0801/ADC0802/ADC0803/ADC0804/ADC0805
www.national.com 2
