Intel387
TM
SX MATH COPROCESSOR
240225–20
Figure 7-6. Float from STEN
240225–21
*In NUMCLK2’s
**or last operand
NOTE:
1. Memory read (operand) cycle is not shown.
Figure 7-7. Other Parameters
40
40
