80C187
CPU/NPX SYNCHRONIZATION
The pins BUSY, PEREQ, and ERROR are used for
various aspects of synchronization between the
CPU and the NPX.
BUSY is used to synchronize instruction transfer
from the CPU to the 80C187. When the 80C187 rec-
ognizes an ESC instruction, it asserts BUSY. For
most ESC instructions, the CPU waits for the
80C187 to deassert BUSY before sending the new
opcode.
The NPX uses the PEREQ pin of the CPU to signal
that the NPX is ready for data transfer to or from its
data FIFO. The NPX does not directly access mem-
ory; rather, the CPU provides memory access serv-
ices for the NPX.
Once the CPU initiates an 80C187 instruction that
has operands, the CPU waits for PEREQ signals that
indicate when the 80C187 is ready for operand
transfer. Once all operands have been transferred
(or if the instruction has no operands) the CPU con-
tinues program execution while the 80C187 exe-
cutes the ESC instruction.
In 8086/8087 systems, WAIT instructions are re-
quired to achieve synchronization of both com-
mands and operands. The 80C187, however, does
not require WAIT instructions. The WAIT or FWAIT
instruction commonly inserted by high-level compil-
ers and assembly-language programmers for excep-
tion synchronization is not treated as an instruction
by the 80C186 and does not provide exception trap-
ping. (Refer to the section ‘‘System Configuration for
8087-Compatible Exception Trapping’’.)
Once it has started to execute a numerics instruction
and has transferred the operands from the CPU, the
80C187 can process the instruction in parallel with
and independent of the host CPU. When the NPX
detects an exception, it asserts the ERROR
signal,
which causes a CPU interrupt.
OPCODE INTERPRETATION
The CPU and the NPX use a bus protocol that
adapts to the numerics opcode being executed.
Only the NPX directly interprets the opcode. Some
of the results of this interpretation are relevant to the
CPU. The NPX records these results (opcode status
information) in an internal 16-bit register. The
80C186 accesses this register only via reads from
NPX port 00FEH. Tables 10 and 11 define the signal
combinations that correspond to each of the follow-
ing steps.
1. The CPU writes the opcode to NPX port 00F8H.
This write can occur even when the NPX is busy
or is signalling an exception. The NPX does not
necessarily begin executing the opcode immedi-
ately.
2. The CPU reads the opcode status information
from NPX port 00FEH.
3. The CPU initiates subsequent bus cycles accord-
ing to the opcode status information. The opcode
status information specifies whether to wait until
the NPX is not busy, when to transfer exception
pointers to port 00FCH, when to read or write op-
erands and results at port 00FAH, etc.
For most instructions, the NPX does not start exe-
cuting the previously transferred opcode until the
CPU (guided by the opcode status information) first
writes exception pointer information to port 00FCH
of the NPX. This protocol is completely transparent
to programmers.
Bus Operation
With respect to bus interface, the 80C187 is fully
asynchronous with the CPU, even when it operates
from the same clock source as the CPU. The CPU
initiates a bus cycle for the NPX by activating both
NPS1 and NPS2, the NPX select signals. During the
CLK period in which NPS1
and NPS2 are activated,
the 80C187 also examines the NPRD
and NPRW
