80C187
Table 6. Exceptions
Exception Cause
Default Action
(If Exception is Masked)
Invalid Operation on a signalling NaN, Result is a quiet NaN,
Operation unsupported format, indeterminate integer indefinite, or
form (0*
%
, 0/0), (
a %
) BCD indefinite
a
(
b%
), etc.), or stack
overflow/underflow (SF is also set)
Denormalized At least one of the operands is The operand is normalized,
Operand denormalized, i.e. it has the smallest and normal processing
exponent but a nonzero significand continues
Zero Divisor The divisor is zero while the dividend Result is
%
is a noninfinite, nonzero number
Overflow The result is too large in magnitude Result is largest finite
to fit in the specified format value or
%
Underflow The true result is nonzero but too small Result is denormalized
to be represented in the specified format, and, or zero
if underflow exception is masked, denormalization
causes loss of accuracy
Inexact The true result is not exactly representable Normal processing
Result in the specified format (e.g. 1/3); continues
(Precision) the result is rounded according to the
rounding mode
Initialization
After FNINIT or RESET, the control word contains
the value 037FH (all exceptions masked, precision
control 64 bits, rounding to nearest) the same values
as in an 8087 after RESET. For compatibility with the
8087, the bit that used to indicate infinity control (bit
12) is set to zero; however, regardless of its setting,
infinity is treated in the affine sense. After FNINIT or
RESET, the status word is initialized as follows:
#
All exceptions are set to zero.
#
Stack TOP is zero, so that after the first push the
stack top will be register seven (111B).
#
The condition code C
3
–C
0
is undefined.
#
The B-bit is zero.
The tag word contains FFFFH (all stack locations
are empty).
80C186/80C187 initialization software should exe-
cute an FNINIT instruction (i.e. an FINIT without a
preceding WAIT) after RESET. The FNINIT is not
strictly required for 80C187 software, but Intel
recommends its use to help ensure upward compati-
bility with other processors.
8087 Compatibility
This section summarizes the differences between
the 80C187 and the 8087. Many changes have been
designed into the 80C187 to directly support the
IEEE standard in hardware. These changes result in
increased performance by elminating the need for
software that supports the standard.
GENERAL DIFFERENCES
The 8087 instructions FENI/FNENI and FDISI/
FNDISI perform no useful function in the 80C187
Numeric Processor Extension. They do not alter the
state of the 80C187 Numeric Processor Extension.
(They are treated similarly to FNOP, except that
ERROR
is not checked.) While 8086/8087 code
containing these instructions can be executed on
the 80C186/80C187, it is unlikely that the exception-
handling routines containing these instructions will
be completely portable to the 80C187 Numeric Proc-
essor Extension.
The 80C187 differs from the 8087 with respect to
instruction, data, and exception synchronization. Ex-
cept for the processor control instructions, all of the
80C187 numeric instructions are automatically syn-
chronized by the 80C186 CPU. When necessary, the
11
