4/17/98 6-49 Addressing Modes and Data Types
AND Rd, [Rs+]
Bytes: 2
Clocks: 5
Operation: (Rd) <-- (Rd) • ((WS:Rs))
(Rs) <-- (Rs) + 1 (byte operation) or 2 (word operation)
Encoding:
AND [Rd+], Rs
Bytes: 2
Clocks: 5
Operation: ((WS:Rd)) <-- ((WS:Rd)) • (Rs)
(Rd) <-- (Rd) + 1 (byte operation) or 2 (word operation)
Encoding:
AND direct, Rs
Bytes: 3
Clocks: 4
Operation: (direct) <-- (direct) • (Rs)
Encoding:
byte 3: lower 8 bits of direct
AND Rd, direct
Bytes: 3
Clocks: 4
Operation: (Rd) <-- (Rd) • (direct)
Encoding:
byte 3: lower 8 bits of direct
0 1 0 1 SZ 0 1 1 d d d d 0 s s s
0 1 0 1 SZ 0 1 1 s s s s 1 d d d
0 1 0 1 SZ 1 1 0 s s s s 1 direct: 3 bits
0 1 0 1 SZ 1 1 0 d d d d 0 direct: 3 bits
