XA User Guide 6-68 4/17/98
BLT Branch if less than (signed)
Syntax: BLT rel8
Operation: (PC) <-- (PC) + 2
if (N) XOR (V) = 1 then
(PC) <-- (PC + rel8*2)
(PC.0) <-- 0
Description: The branch is taken if the last compare instruction had a destination value that was
less than the source value, in a signed operation. The branch range is +254 bytes to -256 bytes, with
the limitation that the target address is word aligned in code memory.
Note: Refer to section 6.3 for details of branch range
Size: Bit
Flags Updated: none
Bytes: 2
Clocks: 6t/3nt
Encoding:
1 1 1 1 1 0 1 1
rel8
