XA User Guide 6-78 4/17/98
CJNE Rd, #data8, rel8
Bytes: 4
Clocks: 9t/6nt
Encoding:
byte 3: rel8
byte 4: data#8
CJNE Rd, #data16, rel8
Bytes: 5
Clocks: 9t/6nt
Encoding:
byte 3: rel8
byte 4: upper 8 bits of #data16
byte 5: lower 8 bits of #data16
CJNE [Rd], #data8, rel8
Bytes: 4
Clocks: 10t/7nt
Encoding:
byte 3: rel8
byte 4: #data8
CJNE [Rd], #data16, rel8
Bytes: 5
Clocks: 10t/7nt
Encoding:
byte 3: rel8
byte 4: upper 8 bits of #data16
byte 5: lower 8 bits of #data16
1 1 1 0 0 0 1 1
d d d d 0 0 0 0
1 1 1 0 1 0 1 1
d d d d 0 0 0 0
1 1 1 0 0 0 1 1
0 d d d 1 0 0 0
1 1 1 0 1 0 1 1
0 d d d 1 0 0 0
