4/17/98 6-85 Addressing Modes and Data Types
CMP [Rd+offset8], #data16
Bytes: 5
Clocks: 6
Operation: ((WS:Rd)+offset8) - #data16
Encoding:
byte 3: offset8
byte 4: upper 8 bits of #data16
byte 5: lower 8 bits of #data16
CMP [Rd+offset16], #data8
Bytes: 5
Clocks: 6
Operation: ((WS:Rd)+offset16) - #data8
Encoding:
byte 3: upper 8 bits of offset16
byte 4: lower 8 bits of offset16
byte 5: #data8
CMP [Rd+offset16], #data16
Bytes: 6
Clocks: 6
Operation: ((WS:Rd)+offset16) - #data16
Encoding:
byte 3: upper 8 bits of offset16
byte 4: lower 8 bits of offset16
byte 5: upper 8 bits of #data16
byte 6: lower 8 bits of #data16
CMP direct, #data8
Bytes: 4
Clocks: 4
Operation: (direct) - #data8
Encoding:
byte 3: lower 8 bits of direct
byte 4: #data8
1 0 0 1 1 1 0 0 0 d d d 0 1 0 0
1 0 0 1 0 1 0 1 0 d d d 0 1 0 0
1 0 0 1 1 1 0 1 0 d d d 0 1 0 0
1 0 0 1 0 1 1 0 0 direct: 3 bits 0 1 0 0
