XA User Guide 6-118 4/17/98
MOV Move Bit to Carry
Syntax: MOV C, bit
Operation: (C) <-- (bit)
Description: Copies the specified bit to the carry flag.
Size: Bit
Flags Updated: none
Note: C is written as the destination of the move, not as a status flag
Bytes:3
Clocks:4
Encoding:
byte 3: lower 8 bits of bit address
0 0 0 0 1 0 0 0
0 0 1 0 0 0 bit: 2
