1-16 Dell PowerEdge Systems — Microprocessor Upgrade Guide
Figure 1-7. Removing the Old Guide Bracket Assembly
Figure 1-8. Installing the New Guide Bracket Assembly
guide bracket
assembly
captive nuts (4)
threaded posts (4)
system board
connector
guide
bracket
assembly
captive nuts (4)
threaded posts (4)
system board
connector
