The low-order byte of this control word configures
exception masking. Bits 5–0 of the control word
contain individual masks for each of the six excep-
tions that the 80C187 recognizes.
The high-order byte of the control word configures
the 80C187 operating mode, including precision,
rounding, and infinity control.
#
The ‘‘infinity control bit’’ (bit 12) is not meaningful
to the 80C187, and programs must ignore its val-
ue. To maintain compatibility with the 8087, this
bit can be programmed; however, regardless of
its value, the 80C187 always treats infinity in the
affine sense (
b%
k
a %
). This bit is initialized
to zero both after a hardware reset and after the
FINIT instruction.
#
The rounding control (RC) bits (bits 11 –10) pro-
vide for directed rounding and true chop, as well
as the unbiased round to nearest even mode
specified in the IEEE standard. Rounding control
affects only those instructions that perform
rounding at the end of the operation (and thus
can generate a precision exception); namely,
FST, FSTP, FIST, all arithmetic instructions (ex-
cept FPREM, FPREM1, FXTRACT, FABS, and
FCHS), and all transcendental instructions.
#
The precision control (PC) bits (bits 9 –8) can be
used to set the 80C187 internal operating preci-
sion of the significand at less than the default of
64 bits (extended precision). This can be useful in
providing compatibility with early generation arith-
metic processors of smaller precision. PC affects
only the instructions ADD, SUB, DIV, MUL, and
SQRT. For all other instructions, either the preci-
sion is determined by the opcode or extended
precision is used.
Table 3. Condition Code Interpretation after FPREM and FPREM1 Instructions
Condition Code Interpretation after
C2 C3 C1 C0
FPREM and FPREM1
Incomplete Reduction:
1 X X X Further Iteration Required
for Complete Reduction
Q1 Q0 Q2 Q MOD 8
000 0
0 1 0 1 Complete Reduction:
0
1 0 0 2 C0, C3, C1 Contain Three Least
1 1 0 3 Significant Bits of Quotient
001 4
011 5
101 6
111 7
Table 4. Condition Code Resulting from Comparison
Order C3 C2 C0
TOP
l
Operand 0 0 0
TOP
k
Operand 0 0 1
TOP
e
Operand 1 0 0
Unordered 1 1 1
