Intel Pentium 4 User Manual

Schematic Review Checklist
R
256 Intel
®
Pentium
®
4 Processor / Intel
®
850 Chipset Family Platform Design Guide
Checklist Items Recommendations Reason/Impact
SA Pins • Should be connected to VCC3_3 or
GND to set the SMBus address for
that RIMM* modules EEPROM.
• If the SMBus is tied to 3.3V
SB
, then
either:
 Provide proper isolation on SCL
/SDA and pull the HIGH SA pins to
3.3 V
OR
 Tie the HIGH SA pins to 3.3V
SB
.
• This sets the SMBus address. Each
device on the SMBus must have an
address to distinguish it from another
device of the same type. That is,
each RIMM* module EEPROM must
be strapped to a different address or
they will all respond on an access.
• Refer to the Rambus datasheets at
http://www.rambus.com
SIN & SOUT Should be daisy-chained between
RIMM connectors:
• MCH SIO pin connects to 1
st
RIMM
connector SIN (B36)
• SOUT (A36) on 1
st
RIMM connector
connects to 2
nd
RIMM connector SIN
(B36)
• A 2.2 kΩ–10 kΩ terminating resistor,
tied to GND, is required on the last
RIMM connector’s SOUT pin.
• Refer to Section 6.1.6.
• Refer to the Rambus datasheets at
http://www.rambus.com
SWE (A57) • If an OEM needs to write to the SPD
devices, it is recommended that this
signal be tied to a GPO pin from
either the ICH2 or the SIO.
• If an OEM does not need to write to
the SPD devices, it is recommended
that this signal be tied to 3.3 V via a
weak pull-up resistor (4.7 k
Ω).
• If SWE = 1, write protected.
• If SWE = 0, not write protected.
• These signals must be driven; do not
leave floating.
• Refer to the RAMBUS datasheets at
http://www.rambus.com
RESET • For the 168-pin RIMM connector, this
is a reserved pin.
• The connector pad is reserved for
future use for the 168-pin RIMM
connector.
• Refer to the RAMBUS datasheets at
http://www.rambus.com
VDD • This is connected to 2.5 V (or 2.5V
SB
)
• It is REQUIRED that the voltage
regulator to the RDRAM* devices
(2.5 V RDRAM device Core) is turned
OFF in S5. This can be
accomplished by connecting the
SLP_S5# signal to the 2.5 V RDRAM
Core voltage regulator.
• It supplies the core voltage for the
RDRAM* technology and interface
logic.
VCMOS • PC600/800/1066:
• This is connected to 1.8 V for
RDRAM technology
• VCMOS must be OFF in S5.
• VCMOS can be generated with a
voltage divider consisting of a 36
Ω
pull-up resistor to VCC2_5 and 100
Ω
resistor to GND.
• S5 is a suspend state and power is
removed from some components on
the motherboard. Therefore, V
CMOS
should be off while in suspend state.
• Refer to Section 6.1.5.

Intel Pentium 4 Specifications

General

Architecture	x86
Core Count	1
Microarchitecture	NetBurst
Manufacturer	Intel
Core Names	Willamette, Northwood, Prescott, Cedar Mill
Virtualization Technology	No
Release Date	November 20, 2000
Clock Speed	1.3 GHz to 3.8 GHz
FSB Speed	400 MHz to 1066 MHz
Socket	Socket 423, Socket 478, LGA 775
Introduced	2000
Product Line	Pentium
Front Side Bus	400 MHz to 1066 MHz
Hyper-Threading	Yes (Prescott and later)
64-bit Support	Yes (Prescott and later)
Instruction Set	MMX, SSE, SSE2, SSE3
Discontinued	2008
Process Technology	180 nm, 130 nm, 90 nm, 65 nm
L2 Cache	256 KB, 512 KB, 1 MB, 2 MB
Lithography	180 nm, 130 nm, 90 nm, 65 nm
L1 Cache	8 KB
