2. Setting time difference (TD1 or TD2)
(a) Press the [MENU] key to display MENU .
(b) Select DISP OPTIONS and then LL-TD CONV pressing the [JOG DIAL] or
[ACQ/ENT] key after each selection.
(c) Turn [JOG DIAL] to select LORAN-C TD1 or LORAN-C TD2 .
(d) Turn [JOG DIAL] to set the value of TD1 or TD2, and then press the [JOG DIAL] or
[ACQ/ENT] key to determine the setting.
LORAN-C GRI 4900
LORAN-C TD1 0
00
TD COR. TD1 0.0
TD COR. TD2 0.0
LL-TD CONV
Setting TD1 (Select the item one case lower for TD2.)
3. Setting the correction value (of TD1 or TD2)
(a) Press the [MENU] key to display MENU .
(b) Select DISP OPTIONS and then LL-TD CONV pressing the [JOG DIAL] or
[ACQ/ENT] key after each selection.
(c) Turn [JOG DIAL] to select TD COR. TD1 or TD COR. TD2 .
(d) Turn [JOG DIAL] to set the correction value of TD1 or TD2, and then press the [JOG
DIAL] or [ACQ/ENT] key to determine the setting.
LORAN-C GRI 4900
LORAN-C TD1 0
LORAN-C TD2 0
TD COR. TD1 0.0
0.0 0.0
LL-TD CONV
Setting the correction value of TD1 (Select the item one case lower for TD2.)
3.5.23 Cursor/own-ship position output function [CSR POS]
This function outputs the infomation of the bearing and distance from the current own ship's
position to cursor position.
The above information is output from the processing unit J8.
Outputting the bearing and distance from the current own ship's position to cursor position.
Outputting the bearing and distance from the current own ship's position to cursor position.Outputting the bearing and distance from the current own ship's position to cursor position.
Outputting the bearing and distance from the current own ship's position to cursor position.
(a) Press the [CSR POS] key.
(b) The J8 outputs the cursor position data. (RSD)
Outputting the bearing and distance when the cursor is the own ship's position.
Outputting the bearing and distance when the cursor is the own ship's position.Outputting the bearing and distance when the cursor is the own ship's position.
Outputting the bearing and distance when the cursor is the own ship's position.
(Outputs "bearing = 0","distance = 0")
(Outputs "bearing = 0","distance = 0")(Outputs "bearing = 0","distance = 0")
(Outputs "bearing = 0","distance = 0")
(a) Hold down the [CSR POS] key.
(b) The J8 outputs the cursor position data. (RSD)
