3.7 Other Procedures Required
3.7.1 Confirming software versions [MENU]
The versions of software installed in the processor, antenna, and operation unit can be displayed.
If a failure occurs, inform our engineer of the software versions as well as details on the failure.
Take the following steps to confirm the software versions:
Take the following steps to confirm the software versions:Take the following steps to confirm the software versions:
Take the following steps to confirm the software versions:
(a) Press the [MENU] key to display MENU .
(b) Select INFORMATION and then SOFTWARE VER. pressing the [JOG DIAL] or
[ACQ/ENT] key after each selection.
The software versions are displayed as shown below.
MAIN V 1.00
2003/01/01
PANEL V 1.00
PANEL2 V 1.00
SCANNER V 1.00
ATA V 1.00
NSK ------
SOFTWARE VER.
3.7.2 Confirming the operating status of connected units [MENU]
The status of the units (e.g., the processor, antenna, and operation unit) currently connected to
this radar can be displayed.
If a failure occurs, inform our engineer of the unit connection status as well as details on the
failure.
Take the following steps to confirm the unit connection status:
Take the following steps to confirm the unit connection status:Take the following steps to confirm the unit connection status:
Take the following steps to confirm the unit connection status:
(a) Press the [MENU] key to display MENU .
(b) Select INFORMATION and then PORT CONNECT pressing the [JOG DIAL] or
[ACQ/ENT] key after each selection.
The unit connection status is displayed as shown below.
GPS NMEA0183
COMPASS JLR-10
PC NMEA0183
SCANNER CONNECT
PANEL CONNECT
PANEL2 NONE
ATA NONE
PORT CONNECT
