(e) Subsequently, the right menu below is displayed. Operate [JOG DIAL] to select the color
to be set, and then press the [JOG DIAL] or [ACQ/ENT] key to determine the selection.
INSIDE BLUE INSIDE BLUE
OUTSIDE BLUE BLACK BLUE
ECHO COLOR BLUE COLOR
TRAIL-TIME BLUE GRAY BLUE
TRAIL-CONT BLUE TRAIL-CONT BLUE
DAY1 DAY1
3. Switching the brightness of the screen [DIMM]
The brightness of the screen can be changed only for screens for which it is selectable.
The brightness of the screen is selectable for ten screens of the five PPI system screens and five
graphic system screens below.
PPI screens (related to radar images)
<1> Background color inside PPI
<2> Background color outside PPI
<3> Echo
<4> Timing trail
<5> Continuous trail
Graphic screens (related to markers and symbols)
<6> (SHM/cursor/WAYPOINT)
<7> (EBL, VRM, fixed marker)
<8> White symbol of MARPA
<9> Red symbol of MARPA
<10> Numeric value display
Take the followi
Take the followiTake the followi
Take the following steps to change the brightness of the screen:
ng steps to change the brightness of the screen:ng steps to change the brightness of the screen:
ng steps to change the brightness of the screen:
(a) Hold down the [DIMM] key to display the DAY/NIGHT menu.
(b) Operate [JOG DIAL] to select BRILLIANCE , and then press the [JOG DIAL] or
[ACQ/ENT] key to determine the selection.
(c) Operate [JOG DIAL] to select the DAY1 , DAY2 , NIGHT1 , or NIGHT2 mode you
want, and then press the [JOG DIAL] or [ACQ/ENT] key to determine the mode.
(This operation determines that the brightness of which pattern of the four is selected.)
(d) The left menu below is displayed. Operate [JOG DIAL] to select one of the following
screen on which you want to set the brightness, and then press the [JOG DIAL] or
[ACQ/ENT] key:
INSIDE , OUTSIDE , ECHO , TRAIL-TIME , TRAIL-CONT ,
HL/CURSOR/WPT , EBL/VRM/RR , ATA WHITE , ATA RED , CHARACTER ,
and PANEL DIMMER
(e) Finally, the right menu below is displayed. Operate [JOG DIAL] to select the value as the
brightness to be set, and then press the [JOG DIAL] or [ACQ/ENT] key to determine the
selection.
