Chapter 8 Specifications
8.1 General Specifications
1) Picture Color PPI by raster scan system
Resolution : 640 x 480 pixels
2) Display screen 10.4-inch TFT Color LCD
3) Range scale <JMA-5104>
0.125nm, 0.25nm, 0.5nm, 0.75nm, 1.5nm, 3nm,
6nm, 12nm, 24nm, 48nm
<JMA-5106 / JMA-5110>
0.125nm, 0.25nm, 0.5nm, 0.75nm, 1.5nm, 3nm,
6nm, 12nm, 24nm, 48nm, 72nm
4) Minimum range Better than 25m
5) Range discrimination Better than 25m
6) Bearing accuracy Better than 1˚
7) Bearing representation Relative, or true with a compass
8) Environmental condition <Temperature>
Scanner unit : -25 ˚C to +55 ˚C
Display unit : -15 ˚C to +50 ˚C
<Relative humidity>
Scanner unit : 93% maximum at +40 ˚C
Display unit : 93% maximum at +40 ˚C
9) Tolerance of input voltage <JMA-5104 / JMA-5106>
DC 12V/24V/32V (from DC 10.8 to 42V)
<JMA5110>
DC 24V/32V (from DC 21.6 to 26.4V)
AC 100/110/115/200/220/230V ± 10%
(by rectifier unit)
10) Power consumption <JMA-5104>
70W
<JMA-5106>
85W
<JMA-5110>
130W
11) Preheating time 90 seconds
12) Dripproof Scanner unit IPX6
Processing unit/Keyboard unit IPX2
Display unit IPX5
13) Vibrations ICE60945
14) Language English, French, Spanish, Norwegian, Italian,
Danish, Japanese
