154
9.7 Initialization
This section describes how to initialize radar equipment. Initialization of radar equipment is
necessary when using it for the first time.
Initialization involves the following tasks.
9.7.1 Adjusting a receiver [+RANGE-] [TX/PRF] [AUTO-TUNE] [MENU]
1. Tuning preset
2. Center frequency adjustment
3. Tuning indicator level adjustment
9.7.2 Noise level adjustment [MENU]
9.7.3 Azimuth adjustment [TM/RM] [AZI MODE] [MENU]
9.7.4 0 mile adjustment [TM/RM] [AZI MODE] [MENU]
9.7.5 Setting a scanner unit height [MENU]
9.7.6 Setting a gyro value [MENU] [AZI MODE]
Caution
●
●●
● Initialize radar equipment before using it for the first time.
Without initialization, radar equipment can neither indicate targets nor measure
distances and azimuths.
Caution
●
●●
● Do not turn off the power until the following adjustments are completed.
Otherwise, an error occurs in the memory of the setting values that were
adjusted internally and, in the worst case, the equipment may not function.
●
●●
● The initialization menu "Setting at installation" can be displayed by pressing the
[MENU] key in long mode.
Text "Initialization menu described above" is displayed in the description
provided below. This setting indicates the menu indication method.
To Next Page
