(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
DATA/IN OUT and NMEA OUT and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select the output times to be changed from GGA ,
GLL , RMC , VTG , OSD , RSD , and TTM by turning [JOG DIAL] and press
[JOG DIAL] or [ACQ/ENT].
(c) Set an output frequency by turning [JOG DIAL] and end the operation by pressing [JOG
DIAL] or [ACQ/ENT].
GGA 0SEC
0SEC 0SEC
RMC 0SEC
VTG 0SEC
OSD 0SEC
RSD 0SEC
TTM 0SEC
CURSOR POS. OFF
NMEA OUT
Example : Changing GGA output time
Use the following procedure to set the
Use the following procedure to set the Use the following procedure to set the
Use the following procedure to set the [CSR POS] key output to ON or OFF.
key output to ON or OFF. key output to ON or OFF.
key output to ON or OFF.
(a) Select CURSOR POS. on the menu shown in (b) above and press [JOG DIAL] or
[ACQ/ENT].
(b) Select OFF or ON by turning [JOG DIAL] and end the operation by pressing [JOG
DIAL] or [ACQ/ENT].
GGA 0SEC
GLL 0SEC
RMC 0SEC
VTG 0SEC
OSD 0SEC
CURSOR POS. 0SEC
OFF 0SEC
ON OFF
NMEA OUT
9.8.30 Setting selection of a magnetic azimuth sensor correction value [MENU]
Set whether correction values are set manually or RMC data is used when connecting a magnetic
azimuth sensor.
Select whether correction values are set manually using a magnetic compass or RMC DATA is
used.
Note
When RMC data is set in the following settings and RMC data is not set, 0 degree is assumed for the
correction value.
Use the following procedure to set selection of a magnetic azimuth sensor correction value.
Use the following procedure to set selection of a magnetic azimuth sensor correction value.Use the following procedure to set selection of a magnetic azimuth sensor correction value.
Use the following procedure to set selection of a magnetic azimuth sensor correction value.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
DATA/IN OUT , CALIBRATION , and MAG CORR. and press [JOG DIAL] or
[ACQ/ENT].
