JRC JMA-5104 User Manual

95
5.5 Circuit Blocks for Repair
NKE-2042
Name Unit/ type of circuit Remarks
Modulator circuit CME-322
Receiver CAE-475
Motor unit H-7BDRD0023
NKE-2062
Name Unit/ type of circuit Remarks
Modulator circuit CME-323
Receiver CAE-475-1
Motor unit CBP-153
NKE-2102
Name Unit/ type of circuit Remarks
Modulator circuit CPA-248
Receiver CAE-475-1
Motor unit CBP-167
Power supply circuit CBD-1645
NDC-1260
Name Unit/ type of circuit Remarks
Main control circuit CMC-1190
Power supply circuit CBD-1638
MARPA circuit CDC-1144 Option
NCE-7640
Name Unit/ type of circuit Remarks
Keyboard circuit CCK-892
NWZ-146
Name Unit/ type of circuit Remarks
LCD unit H-7WZNA0701
Power supply unit CBF-30
