9.8.12 Setting target expansion function control [MENU]
Use this function to set whether the target expansion function can be set to ON in the main menu.
Use the following procedure to set a video gradation leve
Use the following procedure to set a video gradation leveUse the following procedure to set a video gradation leve
Use the following procedure to set a video gradation level.
l.l.
l.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
RADAR , RADAR SETTING , and TGT EXP PROC , and press [JOG DIAL] or
[ACQ/ENT].
(b) When the following menu is displayed, select ON by turning [JOG DIAL] and end the
operation by pressing [JOG DIAL] or [ACQ/ENT].
VIDEO LATITUDE NARROW
VD NOISE REJ LEVEL1
S-BUOY DETECT OFF
F-NET DETECT OFF
IR SHIFT OFF
DR RANGE CONT OFF
TGT EXP PROC LEVEL1
OFF OFF
ON 0
RADAR SETTING
9.8.13 Setting a sensitivity correction value [MENU]
Use this function to increase or reduce the sensitivity temporarily by increasing or reducing the
noise level value when setting function key sensitivity correction to ON for distant targets.
A sensitivity correction value can be set within the range from
A sensitivity correction value can be set within the range from A sensitivity correction value can be set within the range from
A sensitivity correction value can be set within the range from -
--
-32 to +32.
32 to +32.32 to +32.
32 to +32.
Use the following procedure to set a sensitivity correction value.
Use the following procedure to set a sensitivity correction value.Use the following procedure to set a sensitivity correction value.
Use the following procedure to set a sensitivity correction value.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
RADAR , RADAR SETTING , and GAIN OFFSET , and press [JOG DIAL] or
[ACQ/ENT].
(b) Select value from -32 to +32 by turning [JOG DIAL] and end the operation by
pressing [JOG DIAL] or [ACQ/ENT].
VIDEO LATITUDE NARROW
VD NOISE REJ LEVEL1
S-BUOY DETECT OFF
F-NET DETECT OFF
IR SHIFT OFF
DR RANGE CONT OFF
TGT EXP LEVEL LEVEL1
GAIN OFFSET OFF
00
RADAR SETTING
