80
3.7.3 Displaying magnetron current [MENU] [+RANGE-]
The current value of magnetron is displayed. The status of magnetron can be interpreted by the
value.
Take the following steps to display magnetron current.
Take the following steps to display magnetron current.Take the following steps to display magnetron current.
Take the following steps to display magnetron current.
(a) Operate the [+RANGE-] key to set 48 mile.
When the range is already set to "48NM", this operation is not necessary.
(b) Hold down the [MENU] key to display the INSTALLATION menu, select RADAR ,
RADAR ADJUST , and MAG.I , and press the [JOG DIAL] or [ACQ/ENT] key.
(c) A value and bar "â– â– â– " is displayed, you can interpret the magnetron status by the
value.
ï¼
ï¼ï¼
ï¼ï¼¡
ＡＡ
ＡＧ
ＧＧ
Ｇ．
．．
．Ｉ
ＩＩ
Ｉ
1
11
1 2
22
27
77
7 â–
â– â–
â– â–
â– â–
â– â–
â– â–
â–
The bar shakes according to the following value.
From 12 to 24 â– â–
From 25 to 37 â– â– â–
From 38 to 50 â– â– â– â–
From 51 to 63 â– â– â– â– â–
From 64 to 76 â– â– â– â– â– â–
From 77 to 89 â– â– â– â– â– â– â–
From 90 to 102 â– â– â– â– â– â– â– â–
From 130 to 115 â– â– â– â– â– â– â– â– â–
From 116 to 127 â– â– â– â– â– â– â– â– â– â–
In the case of 4kw : From 60 to 80 ■■■■■～■■■■■■■■(Approximately)
In the case of 6kw : From 70 to 90 ■■■■■■～■■■■■■■■■(Approximately)
In the case of 10kw : From 70 to 90 ■■■■■■～■■■■■■■■■(Approximately)
The shaking bar may be shifted, even if it is a new magnetron.
Certainly use this display as a reference.
