58
(a) Hold down the [TRAILS] key to display the TRAILS menu.
(b) Operate [JOG DIAL] to select TRAIL REF LVL , and then press the [JOG DIAL] or
[ACQ/ENT] key.
(c) The menu below is displayed. Select the threshold (level) you want to set, and then press
the [JOG DIAL] or [ACQ/ENT] key to determine the selection.
TRAIL INTERVAL 6M
TRAIL REF LVL 8
8 0.0NM
TRAIL CLEAR OFF
RANGE TRAIL CLEAR
TRAILS
5. Setting a trail storage suppression distance [TRAILS]
The trail storage suppression distance is a function not to store the data of trails in a specified
distance from the own ship.
Use the function not to store the data of unnecessary trails due to wave splash when the own ship sails.
To turn OFF the storage suppression function, set "0" in the procedure below.
Take the following steps to set a trail storage suppression distance:
Take the following steps to set a trail storage suppression distance:Take the following steps to set a trail storage suppression distance:
Take the following steps to set a trail storage suppression distance:
(a) Hold down the [TRAILS] key to display the TRAILS menu.
(b) Operate [JOG DIAL] to select TRAIL SUPRESS , and then press the [JOG DIAL] or
[ACQ/ENT] key.
(c) The menu below is displayed. Turn [JOG DIAL] to set a distance from the own ship in
which you do not want to store trail data, and then press the [JOG DIAL] or [ACQ/ENT]
key to determine the setting.
TRAIL INTERVAL 6M
TRAIL REF LVL 8
TRAIL SUPRESS 0.0NM
0.0NM OFF
RANGE TRAIL CLEAR
TRAILS
6. Setting a range trail storage [TRAILS]
The range trail storage is a function not to clear the trail storage in temporarily observing a
range other than the present range at the time of the trail storage or the trail display.
Normal setting value is "CLEAR", and the trail is automatically cleared by switched the range.
The trail is not automatically cleared even if the range is switched, set "KEEP" in the
procedure below.
Take the following steps to set a range trail storage:
Take the following steps to set a range trail storage:Take the following steps to set a range trail storage:
Take the following steps to set a range trail storage:
(a) Hold down the [TRAILS] key to display the TRAILS menu.
(b) Operate [JOG DIAL] to select RANGE TRAIL , and then press the [JOG DIAL] or
[ACQ/ENT] key.
(c) The menu below is displayed. Turn [JOG DIAL] to select KEEP , and then press the
[JOG DIAL] or [ACQ/ENT] key to determine the selection.
To Next Page
