JRC JMA-5104 - Canceling Image Processing [MENU]; Setting an Image Processing Range [MENU]

62
(c) The menu below is displayed. Turn [JOG DIAL] to select PROC1 , PROC2 , PROC3 ,
PROC1+3 , or PROC2+3 , and then press the [JOG DIAL] or [ACQ/ENT] key to
determine the selection.
PROCESS IR1
OFF OFF
PROC1 OFF
PROC2 3.0
PROC3 FULL
PROC1+3 OFF
PROC2+3
BASIC
2. Canceling image processing [MENU]
In step (c) above, select OFF to cancel the image processing function.
3. Setting an image processing range [MENU]
Take the following steps to select the processing range of PROC1+3 or PROC2+3:
(a) Press the [MENU] key to display MENU .
(b) Select BASIC and then PROC SW RANGE pressing the [JOG DIAL] or [ACQ/ENT]
key after each selection.
The menu below is displayed. Turn [JOG DIAL] to set the range you want, and then
press the [JOG DIAL] or [ACQ/ENT] key to determine the setting.
INTERFERENCE IR1
TGT EXPANSION OFF
PROCESS OFF
PROC SW RANGE 3.0
3.0NM FULL
ZOOM OFF
BASIC
