(b) When the following menu is displayed, select 4800 , 9600 , 19200 , or 38400 by
turning [JOG DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
PANEL 4800
4800 4800
BAUD RATE
9.8.34 Setting a display direction of the indicator [MENU]
Set a display direction of the indicator.
Four indicator display direction are available, 0 degree: HORIZONTAL, 90 degrees:
VERTICAL-RIGHT, 180 degrees: INVERSION, and 270 degrees: VERTICAL-LEFT.
Use the following pr
Use the following prUse the following pr
Use the following procedure to set a display direction of the indicator.
ocedure to set a display direction of the indicator. ocedure to set a display direction of the indicator.
ocedure to set a display direction of the indicator.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
DISPLAY MOUNT and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select HORIZONTAL , VERTICAL-RIGHT ,
INVERSION , or VERTICAL-LEFT by turning [JOG DIAL] and end the operation by
pressing [JOG DIAL] or [ACQ/ENT].
(c) When the system is restarted, the display direction is changed to the selected one.
Note
The above function is also set when the system is started by pressing one of the following keys at
Power ON.
[AUTO-TUNE] : 0 degree : HORIZONTAL
[AUTO-RAIN] : 90 degrees : VERTICAL-RIGHT
[AUTO-SEA] : 180 degrees : INVERSION
[GAIN/PL] : 270 degrees : VERTICAL-LEFT
GYRO SETTING 123.4°
SIMULATION OFF
RADAR >
GPS >
ATA SETTING >
DATA/IN OUT >
DISPLAY MOUNT
HORIZONTAL
VERTICAL-RIGHT
INVERSION
VERTICAL-LEFT
DISPLAY MOUNT
9.8.35 Setting a display timing of the indicator [MENU]
Set a horizontal/vertical display timing of the indicator.
A value between 130 and 160 can be set for a horizontal timing and a value between 20 and 50
can be set for a vertical timing.
Use the follo
Use the folloUse the follo
Use the following procedure to set horizontal display timing of the indicator.
wing procedure to set horizontal display timing of the indicator.wing procedure to set horizontal display timing of the indicator.
wing procedure to set horizontal display timing of the indicator.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
LCD SETTING and HS DISP SATART and press [JOG DIAL] or [ACQ/ENT].
