3.7.4 Confirming error logs [ALARM ACK]
If any of the sensors malfunctions, the error log function lists faulty locations.
If a failure occurs, inform our engineer of the error log contents as well as details on the failure.
Take the following steps to confirm error logs:
Take the following steps to confirm error logs:Take the following steps to confirm error logs:
Take the following steps to confirm error logs:
(a) Hold down the [ALARM ACK] key to display the ALARM menu.
(b) Select ERROR LOG , and then press the [JOG DIAL] or [ACQ/ENT] key.
Error logs are displayed as shown below.
BACK
CPA/TCPA 1
GZ 3
LOST 2
PRC-TRIGER 1
NEXT
ERROR LOG
Error list
When a error occurs, the following error is displayed at the lower right of the screen, and is
saved in the error log.
When you connect to our company or an agency, tell contents of the error log at the time of
failure.
TRX No communication error with transmitter or receiver
TRX-DATA Data error with transmitter or receiver
PANEL No communication error with control unit
PANEL DATA Data error with control unit
PANEL2 No communication error with subcontrol unit
PANEL2 DAT Data error with subcontrol unit
GPS No communication error with GPS equipment
GPS DATA Data error with GPS equipment
GPS STATUS Status error with GPS equipment
COMPASS No communication error with magnetic compass equipment
COMP DATA Data error with magnetic compass equipment
PC No communication error with personal computer
PC DATA Data error with personal computer
NSK No communication error with NSK unit
NSK DATA Data error with NSK unit
GYRO Status error with NSK unit
LOG Status error with NSK unit
GPS COMP No communication error with GPS compass
GCOMP DATA Data error with GPS compass
TRX-HEATER Heater error of transmitter or reciever
