85
3.8 Options
3.8.1 Operating a second keyboard unit [GAIN/PL] [JOG DIAL]
By adding the optional keyboard (NCE-7640), either of the two keyboards can be used
independently to control one antenna.
When one keyboard is being used, it will not be possible to use the other keyboard, with the
exception of a few functions (e.g., the keyboard switching operation and changing from
transmission to standby).
Take the following steps to switch bet
Take the following steps to switch betTake the following steps to switch bet
Take the following steps to switch between keyboard 1 and keyboard 2.
ween keyboard 1 and keyboard 2.ween keyboard 1 and keyboard 2.
ween keyboard 1 and keyboard 2.
(a) Hold down the [GAIN/PL] key to display the following menu.
PANEL1
PANEL2
PANEL CONTROL SELECTION
(b) Turn the [JOG DIAL] to select PANEL 1 or PANEL 2 , then press the [JOG DIAL] or
[ACQ/ENT] key.
(c) The menu below is displayed. Select YES , and then press the [JOG DIAL] or [ACQ/ENT]
key.
PANEL SELECTED
ARE YOU SURE?
NO
YES
PANEL CONTROL SELECTION
(d) When a keyboard other than the one being used is selected from this status, only the
[GAIN/PL] key and [STBY] key will work. The other keys will not function. In order to
be able to use the current keyboard, repeat the above process from (a), then select a
keyboard other than the one selected in step (b) to set the current keyboard for operation.
Note
Even if the keyboard currently being used does not have the operating rights, the [STBY] key on the
keyboard will still be effective as explained above.
This is to allow either keyboard to immediately switch the system from transmission to standby when
there is an emergency.
Therefore, a keyboard that does not have operation rights can switch the system to standby, but it
cannot change it back to the transmission mode. In order to return the system to the transmission
mode, either the keyboard with the operating rights should be used, or the above procedure from (a)
should be followed to acquire the operating rights, then switch the system to the transmission mode.
