169
In the menu shown above, a speed of 0.125 miles of 6KW is set. As shown in the menu on the
left-hand side, each range/pulse width can be changed for each pulse width within the range.
Caution
●
●●
● There is no scanner unit rotation speed function in 4KW.
9.8.16 Setting information in a GPS receiver
In this section, initial values are set in a GPS receiver (GPS receiver of JRC).
1. Setting the position of your own ship [MENU]
Transmit latitude and longitude information of the position of your own ship to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and POSITION , [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, set the South and the North of the latitude, unit of
the degree, unit of the minute, and the unit of the second sequentially. As the procedure
for those settings, change the numbers by turning [JOG DIAL], determine the entry of
each item by pressing [JOG DIAL] or [ACQ/ENT]. When the information up to the second
of the latitude is determined, the cursor moves to the longitude line. Change the settings
of the East and the West of the longitude, the unit of the degree, the unit of the second in
that sequence by turning [JOG DIAL], determine the entry of each item by pressing [JOG
DIAL] or [ACQ/ENT], and end the operation.
POSITION N 36°36.000'
N 36°36.000' E136°36.000'
E136°36.000' 10M
GEODETIC DATUM WGS-84
FIX MODE AUTO
HDOP LEVEL 10
AVERAGE MANUAL 2S
EXCLUDE SAT 00 00 00
00 00 00
MASTER RESET
TX COMMAND
GPS SETTING
2. Setting a height of own ship [MENU]
Send a height of your own ship to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and ANTENNA HEIGHT , and press [JOG DIAL] or
[ACQ/ENT].
