192
LOAD YOUR
MENU SETTING
ARE YOU SURE?
NO
YES
LOAD
As a result of the operation indicated above, the data that was set by initialization is returned.
9.8.37 Initializing a menu storage area [MENU]
Initialize all the menu areas other than the initialization area (installation setting storage area).
Use the following procedure to initialize menu storage areas.
Use the following procedure to initialize menu storage areas.Use the following procedure to initialize menu storage areas.
Use the following procedure to initialize menu storage areas.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
INIT MENU and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select YES to initialize the areas or NO not
to initialize the areas by turning [JOG DIAL] and end the operation by pressing [JOG
DIAL] or [ACQ/ENT].
INITIALIZE YOUR
MENU SETTING
ARE YOU SURE?
NO
YES
LOAD
9.8.38 Displaying simulator images
Demonstration screens can be displayed on PPI by validating this function.
Use the following procedure to set a simulator mode.
Use the following procedure to set a simulator mode. Use the following procedure to set a simulator mode.
Use the following procedure to set a simulator mode.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
SIMULATION and press [JOG DIAL] or [ACQ/ENT].
(b) Using [JOG DIAL], invert characters INTERNAL when using a built-in simulator and
EXTERNAL when using an external simulator (NDW-51 and so on) among OFF ,
INTERNAL , and EXTERNAL , and end the operation by pressing [JOG DIAL] or
[ACQ/ENT].
GYRO SETTING 123.4°
SIMULATION OFF
OFF
INTERNAL
EXTERNAL
DATA/IN OUT >
BAUD RATE >
DISPLAY MOUNT>
LCD SETTING >
BACKUP MEMORY>
INIT MENU >
INSTALLATION
