JRC JMA-5104 User Manual

164
Use the following procedure to set a video gradation level.
Use the following procedure to set a video gradation level.Use the following procedure to set a video gradation level.
Use the following procedure to set a video gradation level.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
RADAR , RADAR SETTING , and VD NOISE REJ , and press [JOG DIAL] or
[ACQ/ENT].
(b) When the following menu is displayed, select OFF , LEVEL 1 , or LEVEL 2 by
turning [JOG DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
VIDEO LATITUDE NARROW
VD NOISE REJ LEVEL1
OFF OFF
LEVEL1 OFF
LEVEL2 OFF
DR RANGE CONT OFF
TGT EXP LEVEL LEVEL1
TGT EXP PROC OFF
GAIN OFFSET 0
RADAR SETTING
9.8.7 Setting a small target detection mode [MENU]
This function detects a distant faint target on a radar image.
To detect a distant faint target, increase a detection probability by reducing the scanner unit
rotation speed and focusing radio waves of the radar to a distant faint target.
Note
Since 4kw is a radome type and does not have a motor rotation control function, this function does not
operate even if it is set to ON.
Use
Use Use
Use the following procedure to set a small target detection mode.
the following procedure to set a small target detection mode.the following procedure to set a small target detection mode.
the following procedure to set a small target detection mode.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
RADAR , RADAR SETTING , and S-BUOY DETECT , and press [JOG DIAL] or
[ACQ/ENT].
(b) When the following menu is displayed, select ON by turning [JOG DIAL] and end the
operation by pressing [JOG DIAL] or [ACQ/ENT].
VIDEO LATITUDE NARROW
VD NOISE REJ LEVEL1
S-BUOY DETECT OFF
OFF OFF
ON OFF
DR RANGE CONT OFF
TGT EXP LEVEL LEVEL1
TGT EXP PROC OFF
GAIN OFFSET 0
RADAR SETTING
