JRC JMA-5104 - Setting Geodetic Information [MENU]

170
(b) When the following menu is displayed, change the numbers using [JOG DIAL], and if a
required value is set, end the operation by pressing [JOG DIAL] or [ACQ/ENT].
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
10M WGS-84
FIX MODE AUTO
HDOP LEVEL 10
AVERAGE MANUAL 2S
EXCLUDE SAT 00 00 00
00 00 00
MASTER RESET
TX COMMAND
GPS SETTING
3. Setting geodetic information [MENU]
This function sets geodetic information of the current position of own ship and sends the
information to a GPS receiver.
Use the following procedure
Use the following procedureUse the following procedure
Use the following procedure to set geodetic information to a GPS receiver.
to set geodetic information to a GPS receiver. to set geodetic information to a GPS receiver.
to set geodetic information to a GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and GEODETIC DATUM , and press [JOG DIAL] or
[ACQ/ENT].
(b) When the following menu is displayed, set the required geodetic information by turning
[JOG DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
GEODETIC DATUM WGS-84
WGS-84
AUTO
10
AVERAGE MANUAL 2S
EXCLUDE SAT 00 00 00
00 00 00
MASTER RESET
TX COMMAND
GPS SETTING
