191
(b) When the following menu is displayed, set a required value by turning [JOG DIAL] and
end the operation by pressing [JOG DIAL] or [ACQ/ENT].
HS DISP SATART 100
100 200
LCD SETTING
Use the following procedure to set vertical display timing of the indicator.
Use the following procedure to set vertical display timing of the indicator.Use the following procedure to set vertical display timing of the indicator.
Use the following procedure to set vertical display timing of the indicator.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
LCD SETTING and VS DISP SATART and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, set a required value by turning [JOG DIAL] and
end the operation by pressing [JOG DIAL] or [ACQ/ENT].
VS DISP SATART 100
100 200
LCD SETTING
9.8.36 Setting reading/writing setting values to non-initialization memory [MENU]
Various setting values can be stored or read from the area where data is stored permanently even
in non-initialization memory or the area is initialized.
Use the following procedure to write the setting into non
Use the following procedure to write the setting into nonUse the following procedure to write the setting into non
Use the following procedure to write the setting into non-
--
-initialization memory.
initialization memory.initialization memory.
initialization memory.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
BACKUP MEMORY and STORE and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select YES to store data or NO not to store
data by turning [JOG DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
MEMORIZE YOUR
MENU SETTING
ARE YOU SURE?
NO
YES
STORE
As a result of the operation, all the values that were set on the menu or by initialization are
stored in a non-initialization memory and the non-initialization memory is not erased even if
master reset operation is performed.
Therefore, before executing master reset, store the values in the non-initialization memory and
after executing master reset, execute read processing that is described in the next item.
Use the following procedure to set read processing from non
Use the following procedure to set read processing from nonUse the following procedure to set read processing from non
Use the following procedure to set read processing from non-
--
-initialization memory.
initialization memory.initialization memory.
initialization memory.
(a) When the following menu is displayed after execution of (a) indicated above, select YES
to load data or NO not to store data by turning [JOG DIAL] and end the operation by
pressing [JOG DIAL] or [ACQ/ENT].
To Next Page
