187
COURSE IN COMPASS GYRO
MANUAL COURSE 000°
SPEED IN GPS BT
MANUAL SPEED 00.0 KT
POSITION IN GPS
MANUAL POS. N 36°36.000'
E136°36.000'
COMPASS PORT JLR-10(9600)
NSK(9600) DISABLE
JLR-10(9600)
COMPASS(4800)
DATA/IN OUT
The signal formats which can be input from J5 of COMPSS port are as follows.
NSK (9600) : JRC original format
JLR-10 (9600) : JRC original format
COMPASS (4800) : MNEA0183 signal, HDT, HDG,VHW, VHW, HDM
9.8.28 Setting connection of the 2nd keyboard [MENU]
Set the presence or absence of an optional 2nd keyboard.
Set the following information when connecting an optional 2nd keyboard.
Use the following procedure to use the 2nd keyboard.
Use the following procedure to use the 2nd keyboard.Use the following procedure to use the 2nd keyboard.
Use the following procedure to use the 2nd keyboard.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
DATA/IN OUT and 2ND PANEL and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select DISABLE or ENABLE and end the
operation by pressing [JOG DIAL] or [ACQ/ENT].
COURSE IN COMPASS GYRO
MANUAL COURSE 000°
SPEED IN GPS BT
MANUAL SPEED 00.0 KT
POSITION IN GPS
MANUAL POS. N 36°36.000'
E136°36.000'
COMPASS PORT JLR-10(9600)
2ND PANEL DISABLE
DISABLE
ENABLE
DATA/IN OUT
9.8.29 Setting a NMEA data output frequency [MENU]
When an output frequency of NMEA-0183 data that is output from a NMEA output port is set
and the [CSR POS] key is pressed, set ON/OFF for the output of RSD data or OSD data.
An output frequency between 0 second to 99 seconds (0: output OFF) can be set.
Note
See 3, "NMEA0183 standard input/output sentences" of 9.3.9, "Connecting a GPS receiver and NMEA
equipment".
Use the
Use the Use the
Use the following
followingfollowing
following procedure to set a NMEA data output frequency
procedure to set a NMEA data output frequency procedure to set a NMEA data output frequency
procedure to set a NMEA data output frequency
