4. Setting a position fixing mode [MENU]
This function sets a position fixing mode of a GPS receiver and sends the information to a GPS
receiver.
2D cannot obtain height information in two-dimensional position fixing.
3D cannot obtain height information in three-dimensional position fixing.
AUTO automatically selects the optimum of 2D and 3D position fixing.
Use the following procedure to set a position fixing mode to GPS receiver.
Use the following procedure to set a position fixing mode to GPS receiver.Use the following procedure to set a position fixing mode to GPS receiver.
Use the following procedure to set a position fixing mode to GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and FIX MODE , and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select 2D , 3D , or AUTO by turning [JOG
DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
GEODETIC DATUM WGS-84
FIX MODE AUTO
2D 10
3D MANUAL 2S
AUTO 00 00 00
00 00 00
MASTER RESET
TX COMMAND
GPS SETTING
5. Setting a HDOP level [MENU]
This function sends a HDOP level of a GPS receiver to a GPS receiver.
Three HDOP levels, 4, 10, 20 are available. The lower the value, the higher is the precision.
However, position fixing becomes more difficult.
Normally, customers need not set this information.
Normally, customers need not set this information.Normally, customers need not set this information.
Normally, customers need not set this information.
Use th
Use thUse th
Use the following procedure to set a HDOP level to a GPS receiver.
e following procedure to set a HDOP level to a GPS receiver.e following procedure to set a HDOP level to a GPS receiver.
e following procedure to set a HDOP level to a GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and HDOP LEVEL , and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select 4 , 10 , or 20 by turning [JOG DIAL]
and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
GEODETIC DATUM WGS-84
FIX MODE AUTO
HDOP LEVEL 10
4 MANUAL 2S
10 00 00 00
20 00 00 00
MASTER RESET
TX COMMAND
GPS SETTING
