4. Setting a DPGS mode [MENU]
This function sends the DPGS ON/OFF (GPS mode) setting to a DGPS receiver.
When the DPGS mode is set to ON, high precision position information can be obtained using
the information from a beacon station.
When the DPGS mode is set to OFF, information can be obtained with the same precision as
for GPS.
Use the following procedure to set the DPGS mode to ON/OFF.
Use the following procedure to set the DPGS mode to ON/OFF.Use the following procedure to set the DPGS mode to ON/OFF.
Use the following procedure to set the DPGS mode to ON/OFF.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , DGPS SETTING , DGPS MODE and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select either OFF or ON by turning [JOG
DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
MODE AUTO
FREQUENCY 288.0KHZ
DGPS MODE 200BPS
OFF ON
ON
DGPS SETTING
5. Sending updated setting values [MENU]
This function sends the information of items 1 to 4 that was set to GPS to a GPS receiver.
The values sets in items 1 to 4 are not set in the GPS receiver without this transmission
operation even if the values are changed and set on the menu.
Use the following procedure to send updated setting values to a GPS receiver
Use the following procedure to send updated setting values to a GPS receiverUse the following procedure to send updated setting values to a GPS receiver
Use the following procedure to send updated setting values to a GPS receiver.
. .
.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , DGPS SETTING , TX COMMAND and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed and transmission starts, message "TRANSMIT..." is
displayed. If the transmission completes successfully, "COMPLETE!" is displayed. If
the transmission fails, "TX FAILED!" is displayed. In this case, start the procedure from
(a) again.
MODE AUTO
TX COMMAND 288.0KHZ
TRANSMIT… 200BPS
COMPLETE!
DGPS SETTING
