125
9.3.6
Installing a keyboard unit
A
keyboard unit can be installed at any locati
on within a distance of 5m with a processi
ng unit.
Connecting a cable
Connect one cable to a processi
ng unit.
T
urn the ins
ertion plug at th
e rear of the p
rocessing unit t
o the full position
and check that th
e
cable does no
t come off even if
it is pulled
.
The cable is attached to the
keyboard unit.
Check that the cable does no
t
come off even if it is pulled.
151
153
