2.1.3 Structure and the functions of knobs
Four knobs are available.
The knobs are classified into three main modes based on the operation. One type is a knob
knob knob
knob
operation mode
operation modeoperation mode
operation mode and other two are a short mode
short modeshort mode
short mode and a long mode
long modelong mode
long mode, similar to the key operations.
In knob operation mode, the values change according to the rotation of the knob. The short mode
and the long mode are the same operation as for the keys.
The function of each knob is described below.
[AUTO-TUNE] knob
Short mode : Switches to automatic/manual.
Long mode : When the power supply is set to ON while this key is pressed, horizontal
orientation display is set (12 o'clock).
Knob operation : The equipment is tuned when the knob is set to the center.
[AUTO-RAIN] knob
Short mode : Switches to automatic/manual.
Long mode : When the power supply is set to ON while this key is pressed, vertical
clockwise rotation display is set (3 o'clock).
Knob operation : The control function reaches the maximum when the knob is turned to the
full position in the clockwise direction and the minimum when the knob is
turned to the full position in the anti-clockwise direction.
[AUTO-SEA] knob
Short mode : Switches to automatic/manual.
Long mode : When the power supply is set to ON while this key is pressed, horizontal
reverse orientation display is set (6 o'clock).
Knob operation : When the knob is turned to the full position in clockwise direction, the
control function reaches the maximum level and when the knob is turned
to the full position in the anti-clockwise direction, the control function
reaches the minimum level.
[GAIN/PL] knob
Short mode : Switches a transmission pulse width.
Long mode : Displays a panel 1/2 switching menu while the power is supplied.
When the power is not supplied, vertical anti-clockwise rotation display is
set if the power supply is set to ON (9 o'clock).
Knob operation : When the knob is turned to the full position in the clockwise direction, the
sensitivity reaches the maximum level and when the knob is turned to the
full position in the anti-clockwise direction, the sensitivity reaches the
minimum level.
