6. Setting an averaging level [MENU]
This function sends time data for averaging position information that is output from a GPS
receiver to a GPS receiver. Three types of averaging levels, 2 seconds, 10 seconds, and 40
seconds, are available. A lower value represents faster data updating, however, the position
information that is received is uneven.
Normally, custome
Normally, customeNormally, custome
Normally, customers need not set this information.
rs need not set this information.rs need not set this information.
rs need not set this information.
Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.Use the following procedure to set a video gradation level to a GPS receiver.
Use the following procedure to set a video gradation level to a GPS receiver.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , and AVERAGE and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, select 40S , 10S , or 2S by turning [JOG
DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
GEODETIC DATUM WGS-84
FIX MODE AUTO
HDOP LEVEL 10
AVERAGE MANUAL 2S
40S 00 00 00
10S 00 00 00
2S
TX COMMAND
GPS SETTING
7. Setting a prohibited satellite number [MENU]
This function sends a satellite that is prohibited to a GPS receiver among the GPS satellites
that have been launched.
Normally, customers need not set this information.
Normally, customers need not set this information.Normally, customers need not set this information.
Normally, customers need not set this information.
Use the following procedure to set a prohibited satellite number.
Use the following procedure to set a prohibited satellite number.Use the following procedure to set a prohibited satellite number.
Use the following procedure to set a prohibited satellite number.
(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select
GPS , GPS SETTING , EXCLUDE SAT and press [JOG DIAL] or [ACQ/ENT].
(b) When the following menu is displayed, set a satellite number using [JOG DIAL],
determine the entry by pressing [JOG DIAL] or [ACQ/ENT], repeat these steps until all the
information items are entered, and end the operation by returning to the previous menu.
POSITION N 36°36.000'
E136°36.000'
ANTENNA HEIGHT 10M
GEODETIC DATUM WGS-84
EXCLUDE SAT AUTO
00 10
00 MANUAL 2S
00 00 00 00
00 00 00 00
00
00
GPS SETTING
