181

(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select

GPS , WAAS SETTING , NG WAAS , and press [JOG DIAL] or [ACQ/ENT].

(b) When the following menu is displayed, select NO USE or USE by turning [JOG

DIAL] and end the operation by pressing [JOG DIAL] or [ACQ/ENT].

MODE AUTO

RANGING ON

NG WAAS NO USE

NO USE AUTO

USE

WAAS SETTING

4. Setting a satellite number [MENU]

This function sends the setting of a WAAS satellite that is used to a WAAS receiver.

A number between 120 and 138 can be selected automatically.

Use the following procedure to set a number of the WAAS satellite that is used.

Use the following procedure to set a number of the WAAS satellite that is used.Use the following procedure to set a number of the WAAS satellite that is used.

Use the following procedure to set a number of the WAAS satellite that is used.

(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select

GPS , WAAS SETTING , WAAS NO. , and press [JOG DIAL] or [ACQ/ENT].

(b) When the following menu is displayed, select either a number between 120 and 138

or AUTO by turning [JOG DIAL] and end the operation by pressing [JOG DIAL] or

[ACQ/ENT].

MODE AUTO

RANGING ON

NG WAAS NO USE

WAAS NO. AUTO

AUTO

WAAS SETTING

5. Sending updated setting values [MENU]

This function sends the information of items 1 to 4 that was set to WAAS to a WAAS receiver.

The values that are set in items 1 to 4 are not set in the WAAS receiver without this

transmission operation even if the values are changed and set on the menu.

Use the following procedure to send updated setting values to a WAAS receiver.

Use the following procedure to send updated setting values to a WAAS receiver. Use the following procedure to send updated setting values to a WAAS receiver.

Use the following procedure to send updated setting values to a WAAS receiver.

(a) Display the INSTALLATION menu by pressing the [MENU] key in long mode, select

GPS , WAAS SETTING , TX COMMAND and press [JOG DIAL] or [ACQ/ENT].

(b) When the following menu is displayed and transmission starts, message "TRANSMIT..." is

displayed. If the transmission completes successfully, "COMPLETE!" is displayed. If

the transmission fails, "TX FAILED!" is displayed. In this case, start the procedure from

(a) again.

MODE AUTO

RANGING ON

TX COMMAND NO USE

TRANSMIT… AUTO

COMPLETE!
