106
8.5 Display
Unit
Specifications
1) Dimensions
Landscape
W
idth :
290mm
Height :
290mm
Depth :
165mm
Portrait
W
idth :
230mm
Height :
325mm
Depth :
165mm
2) Mass
2.8kg
3) Power
DC 12V in
4) Resolution
640 x 480 pixels input signal
5) Signal impedance
V
ideo (R, G, B) :
75
Ω
Sync horizontal :
1k
Ω
Sync vertical :
1k
Ω
6) Cable length
5m
