104
Radar trails
Gradation 1 level (time wakes, continuance, trails)
Color Time trails : 1 color (sky, white, green)
Continuance trails : 1 color (sky, white, green)
Fixed marker / VRM1/2 / EBL1/2
Color cyan
Character
Color white
Heading line/cursor
Color white
Background color inside PPI black, bule, gray
Background color outside PPI black, bule, gray
14) Heading Head up/North up/Course up
15) Motion Relative motion/True motion/Centerd true motion
16) Guard zone alarm Can be wsitched between "OFF", "IN" and "OUT"
17) Anti-clutter function Anti-Clutter sea : Manual/Auto
Anti-Clutter rain : Manual/Auto
18) Scan correlation function Built in
19) Floating EBL Built in
20) Echo stretch function Built in
21) Parallel index Built in
22) Zoom function Built in
23) Timed TX TX : 1 to 99 rotation
ST-BY : 1 to 99 minutes
24) Cable length 20m (standard)
30m (option) : DC 24V in only
25) Interface
Power in Ship's main
Inputs signal GPS or GPS receiver
GPS compass or electronic compass
GYRO (need NSK unit : option)
26) Output NMEA data (need GPS data)
Cursor position (RSD)
Own data (OSD)
MARPA target data (TTM) with optional MARPA pcb
Ext buzz
