116
When mounting the scanner unit, please check the maximum len
gth of the holding
bolts.
If the bolts are too long, it gives
severe damage to inside of the scanner
.
When mounting the scanner unit, please use
the attached bolts.
The mounting base thickness must not exceed 15mm
(0.6inch).
