3
NKE-2042 (spare parts for 4kw scanner unit) included in the same package as scanner unit 7ZXRD0012
Item name
(model name)
Quantity JRC code Remarks
Fuse (SM6.3) 4 5ZFAD00543
For modulator
(processing unit F2 : 6.3A)
12V
input
Not required −
For motor
(processing unit F3:)
Fuse (SM3.15) 4 5ZFAD00359
For modulator
(processing unit F2 : 3.15A)
24/32V
input
Not required −
For motor
(processing unit F3:)
Note
For the 4kw scanner unit, insertion of F3 in the processing unit (fuse for motor) is not required since the
power supply is shared between the modulator and the motor. Therefore, there are no spare parts.
NKE-2062 (spare parts for 6kw scanner unit) included in the same package as scanner unit 7ZXRD0013
Item name
(model name)
Quantity JRC code Remarks
Fuse (SM6.3) 4 5ZFAD00543
For modulator
(processing unit F2 : 6.3A)
12V
input
Fuse (SM5) 4 5ZFAD00393
For motor
(processing unit F3 : 5A)
Fuse (SM3.15) 4 5ZFAD00359
For modulator
(processing unit F2 : 3.15A)
24/32V
input
Fuse (SM5) 4 5ZFAD00393
For motor
(processing unit F3 : 5A)
Carbon brush
(54531-01)
2 BRXP05247
NKE-2102 (spare parts for 10kw scanner unit) included in the same package as scanner unit 7ZXRD0014
Item name
(model name)
Quantity JRC code Remarks
Fuse (SM5) 4 5ZFAD00393
For modulator
(processing unit F2 : 5A)
24/32V
input
Fuse (SM8) 4 5ZFAD00544
For motor
(processing unit F3 : 8A)
Carbon brush
(54583-01)
2 BRSW00101
