64
The own ship's position is reset to the position at switching to true motion display, and the own
ship starts moving from the position.
Allowable combinations of azimuth modes and motion modes
Available azimuth modes vary depending on the motion mode.
H-UP N-UP C-UP
RM â—‹ â—‹ â—‹
TM × ○ ○
CTM × ○ ○
Difference between TM and CTM
The CTM mode always displays TM-mode images with the own ship as the center.
TM CTM
Own ship display True motion Fixed to the center
Another ship display
True motion display Relative motion display
Image processing True motion True motion
Radar trails True motion display True motion display
Off-center 90% 90%
