Juniper EX2200 Hardware Guide

Action Enter the following command:
user@switch> show interfaces ae0 terse
Interface Admin Link Proto Local Remote
ae0 up up
ae0.0 up up inet 10.10.10.2/24
Meaning The output confirms that the ae0 link is up and shows the family and IP address assigned
to this link.
Related
Documentation
Configuring Aggregated Ethernet Links (CLI Procedure) on page 82•
• Configuring Aggregated Ethernet Interfaces (J-Web Procedure) on page 83
• Example: Configuring Aggregated Ethernet High-Speed Uplinks Between an EX4200
Virtual Chassis Access Switch and an EX4200 Virtual Chassis Distribution Switch
Verifying That EEE Is Saving Energy on Configured Ports
Purpose Verify that enabling EEE saves energy on Base-T Copper Ethernet ports.
Action You can see the amount of energy saved by EEE on an EX Series switch using the show
chassis power-budget-statistics command.
1. View the power budget of an EX Series switch before enabling EEE.
• On an EX6210 switch:
user@switch>show chassis power-budget-statistics
PSU 2 (EX6200-PWR-AC2500) : 2500 W Online
PSU 3 ) : 0 W Offline
Total Power supplied by all Online PSUs : 2500 W
Power Redundancy Configuration : N+1
Power Reserved for the Chassis : 500 W
Fan Tray Statistics Base power Power Used
FTC 0 : 300 W nan W
FPC Statistics Base power Power Used PoE
power Priority
FPC 3 (EX6200-48T) : 150 W 61.54 W
0 W 9
FPC 4 (EX6200-SRE64-4XS) : 100 W 48.25 W
0 W 0
FPC 5 (EX6200-SRE64-4XS) : 100 W 48.00 W
0 W 0
FPC 7 (EX6200-48T) : 150 W 63.11 W
0 W 9
FPC 8 (EX6200-48T) : 150 W 12.17 W
0 W 9
Total (non-PoE) Power allocated : 950 W
Total Power allocated for PoE : 0 W
Power Available (Redundant case) : 0 W
Total Power Available : 1550 W
• On an EX4300 switch:
user@switch>show chassis power-budget-statistics fpc 1
235Copyright © 2015, Juniper Networks, Inc.
Chapter 4: Routine Monitoring

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
