Table 11: Port Edit Options (continued)
Your ActionFunctionField
IP Options
1. Select the IPv4 address check box to specify an IPv4
address.
2. Type an IP address—for example: 10.10.10.10.
3. Enter the subnet mask or address prefix. For example,
24 bits represents 255.255.255.0.
4. Click OK.
Specifies an IPv4 address for the interface.
NOTE: If the IPv4 Address check box is cleared,
the interface still belongs to the inet family.
IPv4 Address
1. Select the IPv6 address check box to specify an IPv6
address.
2. Type an IP address—for example:
2001:ab8:85a3::8a2e:370:7334.
3. Enter the subnet mask or address prefix.
4. Click OK.
NOTE: IPv6 address is not supported on EX2200 and
EX4500 switches.
Specifies an IPv6 address for the interface.
NOTE: If the IPv6 Address check box is cleared,
the interface still belongs to the inet family.
IPv6 Address
Table 12: Recommended CoS Settings for Port Roles
Recommended SettingsCoS Parameter
There are four forwarding classes:
•
voice—Queue number is set to 7.
•
expedited-forwarding—Queue number is set to 5.
•
assured-forwarding—Queue number is set to 1.
•
best-effort—Queue number is set to 0.
Forwarding Classes
The schedulers and their settings are:
•
Strict-priority—Transmission rate is set to 10 percent and buffer size to 5 percent.
•
Expedited-scheduler—Transmission rate is set to 30 percent, buffer size to 30 percent, and
priority to low.
•
Assured-scheduler—Transmission rate is set to 25 percent, buffer size to 25 percent, and
priority to low.
•
Best-effort scheduler—Transmission rate is set to 35 percent, buffer size to 40 percent, and
priority to low.
Schedulers
When a desktop and phone, routed uplink, or Layer 2 uplink role is applied on an interface, the
forwarding classes and schedulers are mapped using the scheduler map.
Scheduler maps
Imports the default ieee-802.1 classifier configuration and sets the loss priority to low for the
code point 101 for the voice forwarding class.
ieee-802.1 classifier
Imports the default dscp classifier configuration and sets the loss priority to low for the code
point 101110 for the voice forwarding class.
dscp classifier
Copyright © 2015, Juniper Networks, Inc.40
Network Interfaces for EX4300 Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
