Table 51: show interfaces queue Output Fields (continued)
Field DescriptionField Name
State of the interface. Possible values are:
• Administratively down, Physical link is Down—The interface is turned off, and
the physical link is inoperable.
• Administratively down, Physical link is Up—The interface is turned off, but the
physical link is operational and can pass packets when it is enabled.
• Enabled, Physical link is Down—The interface is turned on, but the physical
link is inoperable and cannot pass packets.
• Enabled, Physical link is Up—The interface is turned on, and the physical link
is operational and can pass packets.
Enabled
Index number of the physical interface, which reflects its initialization sequence.Interface index
SNMP index number for the physical interface.SNMP ifIndex
User-configured interface description.Description
Number of forwarding classes supported and in use for the interface.Forwarding classes
Ingress Queues Information (not shown for all interfaces)
Number of input queues supported and in use on the specified interface. For
an interface on a line card with oversubscribed ports, the ingress queue handles
low priority traffic on the interface.
Ingress queues
Transmission statistics for the queue:
• Packets—Number of packets transmitted by this queue.
• Bytes—Number of bytes transmitted by this queue.
• Tail-dropped packets—Number of packets dropped because the queue
buffers were full.
Transmitted
For an interface on a line card with oversubscribed ports, the number of Packet
Forwarding Engine chassis queues supported and in use for the port group to
which the interface belongs. The Packet Forwarding Engine chassis queue for
a port group handles high priority traffic from all the interfaces in the port group.
PFE chassis queues
Egress Queues Information
Number of output queues supported and in use on the specified interface.Egress queues
CoS queue number.Queue
This counter is not supported on EX Series switches.Queued
Copyright © 2015, Juniper Networks, Inc.302
Network Interfaces for EX4300 Switches

Juniper EX2200 Specifications

General

Throughput	77 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Number of VLANs	1024
Networking standards	-
Switch type	Managed
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Stackable	No
Product color	Black
Power consumption (typical)	100 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	254 mm
Width	441 mm
Height	43 mm
Weight	3600 g
