Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 11
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:ARB:CURR:SQU:TOP[:LEV
] level
[:SOUR[c]]:ARB:VOLT:SQU:TOP[:LEV
] level
[:SOUR[c]]:ARB:CURR:SQU:TOP[:LEV
]?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:SQU:TOP[:LEV
]?
[DEFault|MINimum|MAXimum]
Set the top level of the square waveform
output.
level=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
0
[:SOUR[c]]:ARB:CURR:SQU:TOP:TIME
time
[:SOUR[c]]:ARB:VOLT:SQU:TOP:TIME
time
[:SOUR[c]]:ARB:CURR:SQU:TOP:TIME
?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:SQU:TOP:TIME
?
[DEFault|MINimum|MAXimum]
Set the top time of the square waveform
output. Waveform period must not exceed
1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
[:SOUR[c]]:ARB:CURR:TRAP:END:TIM
E time
[:SOUR[c]]:ARB:VOLT:TRAP:END:TIM
E time
[:SOUR[c]]:ARB:CURR:TRAP:END:TIM
E?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:END:TIM
E?
[DEFault|MINimum|MAXimum]
Set the end time of the trapezoidal
waveform output. Waveform period must
not exceed 1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
[:SOUR[c]]:ARB:CURR:TRAP:FTIM
time
[:SOUR[c]]:ARB:VOLT:TRAP:FTIM
time
[:SOUR[c]]:ARB:CURR:TRAP:FTIM?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:FTIM?
[DEFault|MINimum|MAXimum]
Set the fall time of the trapezoidal
waveform output. Waveform period must
not exceed 1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
Command Summary Reset setting
