2- 12 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:ARB:CURR:TRAP:RTIM
time
[:SOUR[c]]:ARB:VOLT:TRAP:RTIM
time
[:SOUR[c]]:ARB:CURR:TRAP:RTIM?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:RTIM?
[DEFault|MINimum|MAXimum]
Set the rise time of the trapezoidal
waveform output. Waveform period must
not exceed 1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
[:SOUR[c]]:ARB:CURR:TRAP:STAR[:L
EV] level
[:SOUR[c]]:ARB:VOLT:TRAP:STAR[:L
EV] level
[:SOUR[c]]:ARB:CURR:TRAP:STAR[:L
EV]?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:STAR[:L
EV]?
[DEFault|MINimum|MAXimum]
Set the start level of the trapezoidal
waveform output.
level=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
0
[:SOUR[c]]:ARB:CURR:TRAP:STAR:TI
ME time
[:SOUR[c]]:ARB:VOLT:TRAP:STAR:TI
ME time
[:SOUR[c]]:ARB:CURR:TRAP:STAR:TI
ME?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:STAR:TI
ME?
[DEFault|MINimum|MAXimum]
Set the start time of the trapezoidal
waveform output. Waveform period must
not exceed 1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
[:SOUR[c]]:ARB:CURR:TRAP:TOP[:LE
V] level
[:SOUR[c]]:ARB:VOLT:TRAP:TOP[:LE
V] level
[:SOUR[c]]:ARB:CURR:TRAP:TOP[:LE
V]?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRAP:TOP[:LE
V]?
[DEFault|MINimum|MAXimum]
Set the top level of the trapezoidal
waveform output.
level=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
0
Command Summary Reset setting
